M 4K+25 RGB pure laser projector
25,300 lumens, 4K UHD+, 3DLP, RGB pure laser projector
4K UHD+ (3840 x 2400)
Resolution
Solid state pure RGB laser optical system
Illumination type
Illumination performance (hrs)
25,000 hours to 50% brightness when operated at 100% brightness |50,000 hours to 50% brightness when operated at 60% brightness**
Orientation
Omnidirectional
Image processing
Christie TruLife+ electronics, 1.2Gpx/s
Supported frame rates
24-60Hz, Mirage option: 96-120Hz 4K in 2D or 3D @ 60Hz per eye, Mirage Pro option: Mirage + 240-480Hz HD scaled
Sound level
46.7 dBA in quiet fan mode
49.4 dBA in standard fan mode***
Inputs
HDMI 2.1
2 x HDMI 2.0
4 x Micro BNC (12G-SDI)
2 x DisplayPort 1.4
2 x DisplayPort 1.2
Fiber (QSFP+) for use with Christie Link Transmitter (1 input/1 output)
SDVoE (Christie Terra®)
3D Sync (1 Input/1 Output)
Control
Ethernet - Control and Web UI
RS232 (Serial)
GPIO
Wired keypad
User controlled warping and blending
Standard: Christie Twist™ (software can be downloaded at no extra charge)
Optional: Christie Twist Premium and Twist Pro
Automated warping and blending
Standard: Mystique™ Lite (software can be downloaded at no extra charge and requires an off-the-shelf Web/Ethernet camera.)
Optional: Mystique Essentials, Mystique Pro Venue, Mystique Large Scale Experience Edition
Multi-projector management
Christie Conductor software monitors and controls up to 256 projectors and can be downloaded at no extra charge
Line voltage
200-240 VAC 9A 50/60 Hz Single phase
Limited brightness mode: 100-120 VAC 12A 50/60 Hz at half brightness****
Connector: IEC C14 PDU AC inlet (IEC C13 locking cord)
Power consumption
1540W typical (5,250 BTU/hr)
1800W max (6,140 BTU/hr)
Cooling
Liquid, self-contained
Laser class
Class 1 — Risk Group 3
Operating environment
41-104°F (5-40°C)
Relative humidity: 10-80% non-condensing
Dimensions
Size (LxWxH): 24.3 x 20.7 x 10.6" - (617 x 525 x 270 mm)
Weight: 92 lbs. (41.7 kg) without lens
Limited warranty
3 years
