Captiva DWU500S

5,000 lumen, WUXGA, ultra short throw, 1DLP, laser

WUXGA (1920 x 1200)

Resolution

Solid-state laser

Illumination type

20,000 hours

Illumination performance (hrs)

Signal inputs (standard)

• HDMI x 2
• VGA x 1
• VGA audio in (3.5mm phone jack)
• Microphone input
• USB A - for power out only (5V/1.5A)

Max input pixel rate

• 1600 x 1200 @ 60Hz (162 MHz)
• 1920 x 1200 @ 60Hz reduced blanking (154 MHz)

Signal inputs (3D)

• Frame packed/side-by-side/top and bottom 3D (HDMI 1.4a)
• Frame sequential DLP link 3D (VGA/HDMI)
• Frame sequential DLP link 3D (1024 x 768 @120Hz / 1280 x 720 @120Hz)

Pixel clock

• 162 MHz

Signal outputs

• VGA monitor out
• 10W speaker
• Audio output (3.5mm phone jack)

Control and networking

• RS-232 in
• Ethernet (100BaseT) RJ45
• Built-in keypad
• Compatible with Crestron RoomView, AMX, PJ Link

Accessories

• Standard:
• IR remote
• AC Line cord for projector head
• Optional:
• Wall mount

Lens

• 0.25:1 ultra short throw lens
• Focus adjustment
• Fixed offset based on image size

Operating voltage

• 100-240 VAC @ 50/60Hz

Power consumption

• 350W +/-15% @110V max
• 250W +/-15% @110V eco mode

Operating current

• 3.2A +/-15% @110V

Dissipation

• 1373 BTU/hr max
• 981 BTU/hr eco mode

Audible noise

• Standard mode: 36dBA
• Eco mode: 30dBA

Size

• (LxWxH) 12.5 x 15.08 x 3.46" (318 x 383 x 88mm) w/o feet

Weight

• 12.79lbs (5.8kg)

Shipping size

• (LxWxH) 20.4 x 16.5 x 12.9" (518 x 420 x 328 mm)

Shipping weight

• 17.2lbs (7.8 kg)

Operating temperature

• 40-104°F (5-40°C)

Operating humidity

• 10-85% non-condensing

Regulatory

• This product conforms to all relevant European directives, standards, safety, health and environmental concerns
• Directives: RoHS, REACH, WEEE, UL/CSA/IEC 60950-1, FCC Class A, CE, CCC, CU, BIS

Warranty

• Five-year or 20,000-hour warranty, whichever comes first, for models with part number ending in -02 or higher*
• Three-year or 20,000-hour warranty, whichever comes first, for models with part number ending in -01
